The Emerson KJ4010X1-BG1 12P0830X062 supplied by Yueyang Tongtu belongs to the DeltaV M-series I/O subsystem and functions as a carrier module. It does not perform signal conversion or logic processing; its role is to maintain electrical and mechanical connection of the LocalBus, passing both data and power from the left carrier to the right carrier.
This module is typically needed when an existing DeltaV rack has run out of I/O slots and additional carriers are required to accommodate more I/O modules. By installing the Emerson KJ4010X1-BG1 12P0830X062 in the appropriate slot, the LocalBus is extended to the new sub‑rack, allowing the additional I/O modules to be managed by the same controller.
When using this module to add I/O capacity, the DeltaV controller remains unchanged, and the system configuration does not require a full download.
The module carries ATEX Zone 2, IECEx, FM Class I Division 2, CSA, and UKEX certifications. It can be installed directly in industrial sites with flammable gases or dust, such as refineries, chemical plants, and natural gas processing facilities.
The operating temperature range is –40°C to +70°C, making it suitable for outdoor cabinets, non-air-conditioned rooms, and extreme climate conditions.
The module uses a snap-in design. It can be inserted into the backplane guide slots until the latch engages, requiring no special tools.
The module meets ISA-S71.04-1985 Class G3 for airborne contaminant resistance and withstands 10g shock (half-sine, 11ms) and 1mm peak-to-peak vibration.
Before installing or removing the Emerson KJ4010X1-BG1 12P0830X062, the DeltaV rack power must be switched off. The module must not be inserted or withdrawn while the system is energised.
1. Ensure the system is powered off and the area is safe.
2. Align the module with the backplane guide slots and push it in horizontally.
3. Insert until the latch mechanism engages, and verify that the module is flush with adjacent carriers and securely seated.
After installation, no calibration or parameter configuration is required, as the module contains no adjustable components or user-serviceable parts.
1. Removing any carrier module while the system is powered will interrupt LocalBus continuity, causing all downstream carriers to lose communication with the controller.
2. For LocalBus cables crossing between enclosures in hazardous areas, conduit protection per NEC or IEC requirements must be applied.
Before ordering the Emerson KJ4010X1-BG1 12P0830X062, the following items should be verified:
This model is a right extender. If the rack layout requires leftward bus extension, a different model is needed. Check the rack arrangement drawing before placing an order.
Add the widths of all existing and proposed carriers to confirm that the total length does not exceed 6.5 metres. If the total exceeds this limit, consider partitioning the system or adding another controller rather than continuing to chain extenders.
Confirm that the site’s hazardous area classification matches the module’s certifications. This module is suitable for Zone 2 and Class I Division 2. It is not approved for Zone 0 or Zone 1.
The LocalBus provides 12.6 VDC at a maximum of 8A. Each additional carrier and its I/O modules will add to the power consumption. Calculate the current load before expansion to ensure sufficient power reserve.
This model is discontinued. For new projects, assess whether surplus stock will be sufficient for long-term maintenance needs. For existing system expansions or spare parts replenishment, stock channels are generally adequate.
|
Product Model |
Emerson KJ4010X1-BG1 12P0830X062 |
|
Product Type |
Serial Communication Interface Card |
|
Applicable Series |
DeltaV DCS System |
|
Communication Interface |
RS-232 / RS-485 (Depending on Configuration) |
|
Supported Protocols |
Modbus RTU / ASCII and Other Common Protocols |
|
Communication Speed |
Up to 115.2 kbps |
|
Installation Method |
Standard I/O Base Plug-in |
|
Electrical Isolation |
Optical Isolation Protection |
The Emerson KJ4010X1-BG1 12P0830X062 is used in industries that require process automation and system expansion capability:
Oil and gas:refineries, natural gas processing, catalytic cracking units
Chemical and petrochemical: process loops for temperature, pressure, and flow control
Power generation: thermal power plants, gas turbine plants, auxiliary system I/O expansion
Water and wastewater treatment: process control and interlocking for municipal and industrial facilities
Manufacturing and metals: steel mills, mining, and general manufacturing with distributed I/O needs
A: No. Emerson discontinued it on December 31, 2018. Current supply comes from factory surplus or tested used stock.
A: The right extender (KJ4010X1-BG1) passes the LocalBus from the current carrier to the next carrier on the right. The left extender passes it to the left. They have different physical connector orientations and cannot be used interchangeably. Confirm the direction before ordering.
A: No. It is a passive hardware extender with no adjustable components, so no calibration or software setup is needed.
A: No. The system must be fully powered off before any insertion or removal. Hot-swapping will interrupt the LocalBus and may cause communication failures.
A: Beyond 6.5 metres, signal integrity and timing cannot be guaranteed, which may lead to communication errors or module drop‑outs. This limit is due to the electrical drive capability of the bus and cannot be overcome by adding more extenders.
Yueyang Tongtu E-commerce Co., Ltd. has been active in the industrial automation parts trade for over 20 years. Its core business is supplying spare parts for DCS, PLC, robot, and safety control systems, serving end-user plants, system integrators, and engineering maintenance service providers.
Our partner brand portfolio covers more than ten major control systems, including ABB, Honeywell, Bently Nevada, GE Fanuc, Foxboro, Triconex, Yokogawa, Schneider, HIMA, Emerson, and Siemens. Product categories include controllers, I/O modules, power supplies, communication cards, sensors, termination assemblies, racks, and backplane components.
Customers are distributed across industries such as oil, natural gas, chemicals, power, metallurgy, papermaking, automotive manufacturing, water treatment, municipal engineering, and machinery manufacturing.
All products come with a 12-month warranty. For confirmed quality issues, the company covers repair, replacement, or refund, as well as the associated shipping costs. Product condition (new original, tested used) is clearly stated in the quotation, with no concealment of the source, so customers can choose according to their needs.
To inquire about the Emerson KJ4010X1-BG1 12P0830X062 or other DeltaV system components, please provide the following information:
Quotes are typically replied within 24 working hours, including stock status, price, and estimated shipping schedule.
